Infrastructure
The machines behind every casting.
A compact, well-maintained machinery line covering core making, melting, machining, blasting and grinding.
150MT / annum
Casting production capacity
0.1–110kg
Piece weight range handled
150kg
Furnace crucible capacity
8stage
Controlled sand-casting process
Machinery Schedule
Six machine groups, purpose-built.
VMC Machines
2 unitsX-800mm, Y-550mm, Z-550mm travel with rotary table — 1 machine on 4-axis, 2 machines on 3-axis.
Lathe Machines
2 unitsConventional turning machine paired with a conventional drilling machine.
Core Machine
1 unitFully automatic cold-core machine, core capacity up to 25 kg.
Sand Blasting Plant
1 lineDedicated blast machine for part cleaning, 110 kg material throughput per hour.
Melting Furnace
1 unit150 kg crucible, melting capacity of 1 MT per day.
Grinding Machinery
Dedicated lineFettling line for all types of casting, from flash removal to final finish.
In-House Facilities
Every supporting process, under one roof.
No handoffs to outside vendors for the core steps — that keeps lead times short and quality consistent.
- Shell / cold / oil core facility
- Colour core facility
- Machining — VMC & CNC
- Grinding facility
- Vacuum impregnation facility
- Heat treatment facility
- Shot blast & sand blast facility
Our Shops
Four shops, one continuous flow.
From core making through to final machining, each shop is laid out for a smooth handoff to the next.
01Core Shop
Shell, cold-box, oil and CO₂ core production.
02Molding Area
Sand casting and mould assembly.
03Grinding Shop
Fettling, blasting and final finishing.
04VMC Shop
Precision VMC & CNC machining.
Quality Control
Measured, not guessed.
Every batch is checked with calibrated instruments before it's packed for dispatch.
Start a Program
Send your drawing or sample — we’ll cast it right.
From core making to finished, inspected components, Metline Casting runs the full aluminium casting process in-house.
